INDOOR UNIT
COMPACT CASSETTE
AUAG09, 12, 14, 18LVLA
762011.02.25
DECORATION PANEL
UTG-UFYD-W
Name and Shape Q’ty Application
Connector cover
1
For covering
connector
Tapping Screw
(M5 × 12 mm)
4
For mounting
decoration panel
Tapping Screw
(M4 × 12 mm)
1
For mounting
connector cover
L angle
2
For mounting the
hook wire to the
decoration panel
Hook wire
2
For suspending the
Decoration panel
Screw (pitch small)
(M4 × 10 mm)
2
For mounting the hook
wire (for metals)
Screw (pitch large)
(M4 × 10 mm)
4
For mounting the
L angle and hook wire
(for resins)
Name and Shape Q’ty Application
Special nut A (Large ß ange)
4
For installing indoor
unit
Special nut B (Small ß ange)
4
For installing indoor
unit
Template
(Carton top)
1
For cealing openings
cutting
Also used as packing
Drain hose
1
For installing drain
pipe
Hose Band
1
For installing drain
hose
Drain hose
insulation
1
For installing drain
pipe
Remote control
1
For air conditioner
operation
Battery
2
For remote control
Remote control holder
1
For installing the
remote control
Tapping screw
(M3 × 12mm)
2
For mounting the
remote control holder
Binder
2
For electrical wiring
Wire clamper
1
For electrical wiring
Coupler heat
insulation
(Small)
1
For indoor side pipe
joint (Liquid pipe)
Coupler heat
insulation
(Large)
1
For indoor side pipe
joint (Gas pipe)
