OUTDOOR UNIT
ACCESSORIES
Application
For outdoor unit drain
piping work (May not be
supplied, depending on
the model.)
For filling in a gap at the
entrance of connection
cords.
Q’ty
1
1
2
Name and Shape
Drain pipe
Drain cap
Putty
2
1
For connecting a pipe
with different diameter
to the outdoor unit.
Adapter G (1/2" 5/8")
12.7mm 15.88mm
Adapter D (1/2" 3/8")
12.7mm 9.52mm
74
2011.12.21
