Fujitsu AOAG30LAT4 User Manual

INDOOR UNIT
SLIM DUCT
ARAG24LLLA
Parts numberDescriptionRef
712012.01.27
12 Cabinet Panel (4 Fan)
11 Main Panel (4 Fan)
13 Drain Pan Sub Assy
14 Evaporator Total Assy
9380599005
9380604006
9379901062
9380682073
10 Air Filter 93795740063 Pipe Panel Sub Assy
1 Side Panel R Sub Assy
2 Side Panel L Sub Assy
5 Outlet Frame Assy
Parts numberDescriptionRef
Panel (Window) Sub Assy
8 Fan Guard (4 Fan)9379906012
9379900003
9379907019
9380042020
9379915007
9380591009
93795750039 Air Filter
7 Valve Cover Sub Assy 9379576017
6 Front Panel (4 Fan) 9380596004
4
3
12
11
13
7
2
8
10
10
9
4
1
5
6
14
