2-2. Models: AUXG30KRLB, AUXG36KRLB, AUXG45KRLB, and
AUXG54KRLB
Unit: mm
796
342
950
View A
Hanging bolt position
Hanging bolt position
Indoor unit
Drain hose
View B View C
A
B
C
Ceiling
Wire hole
950
620
768
420
293
342
45
40
140
298
200 to 205
10
39
200 to 205
200
237
40
40
164
Fresh air inlet (cut out)
100
83
100
83
352
109
164
90
950
4 × Ø3.2
hole
Ø95
80
80
- 6 -
2-2. Models: AUXG30KRLB, AUXG36KRLB, AUXG45KRLB, and AUXG54KRLB
2. Dimensions
CASSETTE TYPE
AUXG24-54KRLB
CASSETTE TYPE
AUXG24-54KRLB
