Fujitsu AOG30KATA Series Design & Technical Manual

10. Electrical characteristics
Model name AOYG24KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 13.6
Starting current A 8.4
Wiring
spec. *2
Circuit breaker current A 20
Power cable
mm
2
2.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 31
Model name AOYG30KBTB AOYG36KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 22.6
Starting current A 11.1 12.9
Wiring
spec. *2
Circuit breaker current A 25
Power cable
mm
2
4.0
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 51
Model name AOYG45KBTB AOYG54KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 28.5
Starting current A 16.0 19.4
Wiring
spec. *2
Circuit breaker current A 32
Power cable
mm
2
4.0
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 51
*1: Maximum current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. Increase conductor size if voltage drop is 2% or more.
