Fujitsu AOG30KATA Series Design & Technical Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AUXG24KRLB
AFR
m
3
/h
1,150
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 5.66 4.25 0.61 6.30 4.28 0.62 6.52 4.65 0.62 6.95 4.66 0.63 7.16 5.04 0.63 7.59 5.02 0.64 8.02 5.34 0.64
-10 5.70 4.26 0.51 6.35 4.29 0.52 6.57 4.66 0.52 7.00 4.67 0.53 7.22 5.05 0.53 7.65 5.03 0.54 8.09 5.36 0.54
0 5.56 4.20 0.52 6.19 4.22 0.53 6.40 4.59 0.53 6.83 4.60 0.54 7.04 4.97 0.54 7.46 4.95 0.55 7.88 5.27 0.55
5 5.41 4.14 0.66 6.02 4.16 0.67 6.23 4.53 0.67 6.64 4.54 0.68 6.85 4.90 0.69 7.26 4.89 0.69 7.67 5.20 0.70
10 5.37 4.13 0.65 5.98 4.15 0.66 6.19 4.52 0.66 6.60 4.53 0.67 6.80 4.89 0.67 7.21 4.87 0.68 7.62 5.19 0.69
15 5.20 4.06 0.78 5.79 4.08 0.79 5.99 4.44 0.79 6.39 4.45 0.80 6.58 4.81 0.81 6.98 4.79 0.81 7.37 5.10 0.82
20 6.54 4.63 1.39 7.29 4.66 1.41 7.54 5.07 1.42 8.04 5.08 1.43 8.28 5.49 1.44 8.78 5.47 1.45 9.28 5.82 1.47
25 6.15 4.48 1.54 6.85 4.51 1.56 7.09 4.90 1.57 7.55 4.92 1.58 7.79 5.31 1.59 8.25 5.29 1.61 8.72 5.64 1.62
30 5.76 4.34 1.69 6.41 4.36 1.71 6.63 4.74 1.72 7.07 4.76 1.74 7.29 5.14 1.75 7.72 5.12 1.76 8.16 5.45 1.78
35 5.37 4.19 1.82 5.98 4.21 1.85 6.19 4.58 1.86 6.60 4.59 1.88 6.80 4.96 1.89 7.21 4.94 1.91 7.62 5.26 1.93
40 5.09 4.06 1.97 5.67 4.08 2.00 5.87 4.44 2.02 6.26 4.45 2.04 6.45 4.81 2.05 6.84 4.79 2.07 7.22 5.10 2.09
46 4.18 3.59 1.70 4.66 3.61 1.73 4.82 3.93 1.74 5.13 3.94 1.76 5.29 4.25 1.77 5.61 4.24 1.78 5.93 4.51 1.80
¢
Model: AUXG30KRLB
AFR
m
3
/h
1,600
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.18 4.69 1.03 6.40 4.70 1.06 6.54 4.71 1.08 6.91 4.94 1.09 7.27 5.17 1.11 7.68 5.33 1.13 8.29 5.58 1.15
-10 6.05 4.62 1.26 6.26 4.63 1.29 6.41 4.64 1.31 6.76 4.86 1.33 7.12 5.08 1.35 7.52 5.25 1.37 8.12 5.49 1.40
0 5.79 4.47 1.70 6.00 4.48 1.74 6.13 4.49 1.77 6.47 4.70 1.80 6.82 4.92 1.83 7.20 5.08 1.85 7.77 5.31 1.89
5 5.74 4.45 1.75 5.95 4.46 1.79 6.08 4.47 1.82 6.42 4.69 1.85 6.76 4.90 1.88 7.14 5.06 1.91 7.71 5.29 1.95
10 5.69 4.43 1.80 5.89 4.45 1.85 6.03 4.46 1.87 6.36 4.67 1.91 6.70 4.88 1.94 7.07 5.04 1.97 7.64 5.27 2.01
15 5.60 4.36 1.86 5.79 4.37 1.90 5.93 4.38 1.93 6.26 4.59 1.96 6.59 4.80 1.99 6.96 4.96 2.02 7.51 5.19 2.07
20 8.44 6.05 2.06 8.74 6.06 2.11 8.94 6.07 2.14 9.44 6.37 2.18 9.93 6.66 2.21 10.49 6.87 2.25 11.33 7.19 2.29
25 8.04 5.90 2.13 8.32 5.91 2.18 8.51 5.92 2.21 8.98 6.21 2.25 9.46 6.49 2.29 9.99 6.70 2.32 10.78 7.01 2.37
30 7.63 5.75 2.20 7.90 5.76 2.25 8.08 5.77 2.29 8.53 6.05 2.33 8.98 6.33 2.36 9.48 6.53 2.40 10.24 6.83 2.45
35 7.22 5.60 2.27 7.48 5.61 2.32 7.65 5.62 2.36 8.07 5.89 2.40 8.50 6.16 2.44 8.98 6.36 2.48 9.69 6.66 2.53
40 6.76 5.45 2.37 7.00 5.46 2.43 7.16 5.47 2.47 7.56 5.74 2.51 7.95 6.00 2.55 8.40 6.19 2.59 9.07 6.48 2.64
46 6.20 5.27 2.50 6.42 5.28 2.55 6.57 5.29 2.59 6.93 5.55 2.64 7.30 5.80 2.68 7.71 5.99 2.72 8.32 6.26 2.78
- 10 -
4-1. Cooling capacity
