01-14
2-3. HORIZONTAL LOUVER CONTROL
Each time the button is pressed, the air direction range will change as follows:
(Function Range)
(Fig 13 : Air Direction Range)
2-4. SWING OPERATION
When the swing signal is received from the remote controller, the horizontal louver starts to swing.
The range of swing depends on the set airflow direction.
When the indoor fan is either at S-Low or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
( Stop mode means Operation stop.)
The type of operation
Cooling / Heating / Dry / Fan
Range of swing
to
Use the air direction adjustments within the ranges shown above.
The remote control unit's display does not change.
(All range)
12345
15
