1-2. HEATING OPERATION
1-2-1 HEATING CAPACITY CONTROL
A sensor (room temperature thermistor) built in the indoor unit will usually perceive
difference or variation between a set temperature and present room temperature, and
controls the operation frequency of the compressor.
The maximum frequency is limited in the range shown in Figure 2 based on the outdoor temperature.
If the room temperature is lower 3 °C than a set temperature,
the compressor operation frequency will attain to maximum frequency.
If the room temperature is higher 2.5 °C than a set temperature, the compressor
will be stopped.
When the room temperature is between +2.5 °C to -3 °C of the setting temperature,
the compressor frequency is controlled within the range shown in Table 2.
01-02
Minimum
frequency
Maximum
frequency
AO *G36LATT
AO *G45LATT
AO *G54LATT
AOTG60LATT
18rps
18rps
18rps
18rps
80rps
85rps
85rps
85rps
( Table 2 : Compressor Frequency Range )
.
.
.
AO *G36LATT
AO *G36LATT
A zone
B zone
C zone
D~ F zone
Med Low Quiet
Fan speed mode
High
55
55
55
41
55
55
53
41
77
77
59
46
80
80
65
52
80
80
62
52
A zone
B zone
C zone
D~ F zone
A zone
B zone
C zone
D~ F zone
53
53
41
38
53
53
41
38
56
56
46
41
62
62
52
46
62
62
52
46
41
41
38
33
53
53
41
33
46
46
41
37
52
52
46
40
62
62
52
40
31
31
31
27
31
31
31
27
35
35
35
30
38
38
38
33
38
38
38
33
AO *G45LATT
AO *G54LATT
AO *G54LATT
[ rps ]
( Fig 1-2 : Limit of Maximum Frequency based on Outdoor Temperature for Multi type )
A zone
B zone
C zone
D zone
E zone
F zone
36°C
32°C
21°C
12°C
2°C
When the room
temperature rises
Outdoor air
temperature
34°C
30°C
19°C
10°C
0°C
When the room
temperature drops
A zone
B zone
C zone
D~ F zone
A zone
B zone
C zone
D~ F zone
Recital
In the case of the Indoor unit
of Duct or Ceiling type
In the case of the Indoor unit
of Duct or Ceiling type
