Fujitsu AOU24RGLX Design & Technical Manual

Type Inverter heat pump
Model name AOU42RGLX AOU48RGLX
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Starting current A 16.8 20.9
Fan
Airflow rate
Cooling
CFM (m
3
/h)
3,973 (6,750) 4,061 (6,900)
Heating 3,649 (6,200) 4,091 (6,950)
Type × Q'ty Propeller × 2
Motor output W 100
Sound pressure level *
Cooling
dB (A)
55 57
Heating 57 59
Heat exchanger type
Dimensions
(H × W × D)
in (mm)
49-8/5 × 35-7/16 × 1-7/16
(1,260 × 900 × 36.4)
Fin pitch FPI 20
Rows × Stages
2 × 22
2 × 38
Pipe type Copper
Fin
Type (Material) Aluminum
Surface treatment PC Fin
Compressor
Type × Q'ty Twin rotary × 1
Motor output W 3,750
Refrigerant
Type R410A
Charge
lb oz 7 lb 10.1 oz
g 3,450
Refrigerant oil
Type POE (VG74)
Amount
in
3
(cm
3
)
94.6 (1,550)
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR 7.5/1.0
Dimensions
(H × W × D)
Net in (mm)
50-13/16 × 35-7/16 × 13
(1,290 × 900 × 330)
Gross in (mm)
57-1/2 × 41-5/16 × 17-1/2
(1,460 × 1,050 × 445)
Weight
Net
lb (kg)
209 (95)
Gross 231 (105)
Connection pipe
Size
Liquid
in (mm)
Ø3/8 (9.52)
Gas Ø5/8 (15.88)
Method Flare
Pre-charge length
ft (m)
98 (30)
Max. length 246 (75)
Max. height difference 98 (30)
Operation range
Cooling
°F (°C)
-4 to 115 (-20 to 46)
Heating -4 to 75 (-20 to 24)
Drain hose
Material LDPE
Size in (mm) Ø1/2 (13.0) [I.D.], Ø5/8 to Ø11/16 (16.0 to 16.7) [O.D.]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 80 °FDB (26.67 °CDB) / 67 °FWB (19.44 °CWB), and outdoor temperature of 95 °FDB (35 °CDB) / 75 °FWB (23.9 °CWB).
– Heating: Indoor temperature of 70 °FDB (21.11 °CDB) / 59 °FWB (15 °CWB), and outdoor temperature of 47 °FDB (8.33 °CDB) / 43 °FWB (6.11 °CWB).
– Pipe length: 24 ft 6 in (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 100 -
1. Specifications
OUTDOOR UNIT AOU12-48R OUTDOOR UNIT AOU12-48R
