10. Electrical characteristics
Model name AOU12RLFC
Power
supply
Voltage V 208/230~
Frequency Hz 60
MCA *
1
A 13.4
Starting current A 6.7
Wiring spec.
*
2
MAX. CKT. BKR *
3
A 15
Power cable AWG 14
Connection
cable *
4
Size AWG 14
Limited wiring
length
ft (m) 60 (18)
Item Unit
Model name
AOU18RGLX AOU24RGLX AOU30RGLX AOU36RGLX
Power
supply
Voltage V 208/230~
Frequency Hz 60
MCA *1 A 18.3 20.8 24.6
Starting current A 6.6 9.6 11.5 16.1
Wiring spec.
*
2
MAX. CKT. BKR *
3
A 20 30
Power cable AWG 16—14
Connection
cable *
4
Size AWG 20—16
Limited wiring
length
ft (m) 167 (51)
Item Unit
Model name
AOU42RGLX AOU48RGLX
Power
supply
Voltage V 208/230~
Frequency Hz 60
MCA *1 A 25.2 28.3
Starting current A 16.8 20.9
Wiring spec.
*
2
MAX. CKT. BKR *
3
A 30
Power cable AWG 14—10
Connection
cable *
4
Size AWG 18—16
Limited wiring
length
ft (m) 250 (76)
*1: Minimum Circuit Ampacity (Calculation based on UL1995)
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Maximum Circuit Breaker
*4: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
- 132 -
10. Electrical characteristics
OUTDOOR UNIT AOU12-48R OUTDOOR UNIT AOU12-48R
