Fujitsu AOU24RGLX Design & Technical Manual

6-3. Models: AOU42RGLX and AOU48RGLX
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length
m
5 7.5 10 20 30 40 50 60 75
ft 16 24 32 65 98 131 164 196 246
Height difference H
Indoor unit is higher
than outdoor unit *1
30 98 — — — — 0.879 0.847 0.814 0.782 0.743
20 65 — — — 0.927 0.894 0.861 0.828 0.795 0.755
10 32 — — 0.975 0.942 0.909 0.875 0.842 0.808 0.768
7.5 24 — 0.988 0.979 0.946 0.912 0.879 0.845 0.811 0.771
5 16 0.992 0.992 0.983 0.950 0.916 0.882 0.848 0.815 0.774
0 0 1.000 1.000 0.991 0.957 0.923 0.889 0.855 0.821 0.780
Indoor unit is lower
than outdoor unit *2
-5 -16 1.000 1.000 0.991 0.957 0.923 0.889 0.855 0.821 0.780
-7.5 -24 — 1.000 0.991 0.957 0.923 0.889 0.855 0.821 0.780
-10 -32 — — 0.991 0.957 0.923 0.889 0.855 0.821 0.780
-20 -65 — — — 0.957 0.923 0.889 0.855 0.821 0.780
-30 -98 — — — — 0.923 0.889 0.855 0.821 0.780
HEATING
Pipe length
m
5 7.5 10 20 30 40 50 60 75
ft 16 24 32 65 98 131 164 196 246
Height difference H
Indoor unit is higher
than outdoor unit *1
30 98 — — — — 0.978 0.968 0.958 0.948 0.935
20 65 — — — 0.988 0.978 0.968 0.958 0.948 0.935
10 32 — — 0.998 0.988 0.978 0.968 0.958 0.948 0.935
7.5 24 — 1.000 0.998 0.988 0.978 0.968 0.958 0.948 0.935
5 16 1.000 1.000 0.998 0.988 0.978 0.968 0.958 0.948 0.935
0 0 1.000 1.000 0.998 0.988 0.978 0.968 0.958 0.948 0.935
Indoor unit is lower
than outdoor unit *2
-5 -16 0.995 0.995 0.993 0.983 0.973 0.963 0.953 0.943 0.930
-7.5 -24 — 0.993 0.990 0.980 0.970 0.960 0.950 0.940 0.928
-10 -32 — — 0.988 0.978 0.968 0.958 0.948 0.938 0.926
-20 -65 — — — 0.968 0.958 0.948 0.938 0.929 0.916
-30 -98 — — — — 0.948 0.939 0.929 0.919 0.907
- 122 -
6-3. Models: AOU42RGLX and AOU48RGLX 6. Capacity compensation rate for pipe length and height difference
