13. Function settings (For AOU42RGLX and AOU48RGLX)
Perform appropriate function setting locally according to the installation environment.
NOTE: Incorrect settings can cause a product malfunction.
CAUTION
• Before setting up the switch buttons, discharge the static electricity from your body.
• Never touch the terminals or the patterns on the parts that are mounted on the PCB.
13-1. Local setting switch buttons
¢ Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
Terminal block
Switch buttons
LED lamps
- 139 -
13-1. Local setting switch buttons 13. Function settings (For AOU42RGLX and AOU48RGLX)
