Fujitsu AOU24RGLX Design & Technical Manual

¢ Model: ARU42RGLX
AFR CFM 1,501
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 32.16 27.57 1.10 35.83 27.71 1.11 38.26 30.19 1.12 40.70 32.63 1.13 43.15 32.52 1.15 45.61 34.63 1.16
5 31.86 27.46 1.17 35.49 27.61 1.18 37.91 30.07 1.20 40.32 32.51 1.21 42.75 32.40 1.22 45.18 34.50 1.24
14 31.53 27.36 1.21 35.13 27.53 1.22 37.53 29.97 1.24 39.93 32.40 1.24 42.33 32.29 1.26 44.73 34.39 1.27
32 31.26 26.93 1.27 34.80 27.07 1.29 37.19 29.51 1.30 39.57 31.90 1.32 41.94 31.76 1.33 44.31 33.86 1.35
41 30.84 26.86 1.35 34.35 27.04 1.37 36.69 29.43 1.39 39.03 31.83 1.40 41.37 31.69 1.41 43.71 33.79 1.42
50 30.51 26.97 1.43 33.99 27.14 1.45 36.32 29.54 1.47 38.64 31.94 1.48 40.95 31.83 1.50 43.26 33.89 1.51
59 30.30 27.21 1.55 33.78 27.39 1.57 36.08 29.83 1.59 38.37 32.26 1.61 40.68 32.12 1.62 42.99 34.21 1.64
67 31.14 26.50 1.79 34.68 26.68 1.81 37.07 29.04 1.83 39.42 31.41 1.85 41.79 31.30 1.87 44.16 33.33 1.88
77 32.28 27.61 2.13 35.97 27.75 2.16 38.42 30.23 2.19 40.86 32.69 2.20 43.32 32.58 2.23 45.78 34.71 2.25
86 33.90 27.82 3.20 37.77 27.96 3.25 40.35 30.47 3.28 42.93 32.93 3.31 45.51 32.83 3.34 48.06 34.96 3.38
95 33.18 27.61 3.52 36.96 27.78 3.58 39.48 30.25 3.61 42.00 32.72 3.65 44.52 32.58 3.68 47.04 34.71 3.72
104 30.48 26.04 3.63 33.96 26.22 3.68 36.27 28.55 3.72 38.58 30.87 3.75 40.89 30.73 3.79 43.20 32.76 3.83
115 24.78 22.88 3.11 27.60 23.02 3.16 29.48 25.08 3.19 31.35 27.11 3.22 33.24 27.00 3.26 35.13 28.78 3.29
AFR
m
3
/h
2,550
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-20.6 9.43 8.08 1.10 10.50 8.12 1.11 11.21 8.85 1.12 11.93 9.56 1.13 12.65 9.53 1.15 13.37 10.15 1.16
-15 9.34 8.05 1.17 10.40 8.09 1.18 11.11 8.81 1.20 11.82 9.53 1.21 12.53 9.50 1.22 13.24 10.11 1.24
-10 9.24 8.02 1.21 10.30 8.07 1.22 11.00 8.78 1.24 11.70 9.50 1.24 12.41 9.47 1.26 13.11 10.08 1.27
0 9.16 7.89 1.27 10.20 7.93 1.29 10.90 8.65 1.30 11.60 9.35 1.32 12.29 9.31 1.33 12.99 9.92 1.35
5 9.04 7.87 1.35 10.07 7.92 1.37 10.75 8.63 1.39 11.44 9.33 1.40 12.13 9.29 1.41 12.81 9.90 1.42
10 8.94 7.90 1.43 9.96 7.96 1.45 10.64 8.66 1.47 11.33 9.36 1.48 12.00 9.33 1.50 12.68 9.93 1.51
15 8.88 7.98 1.55 9.90 8.03 1.57 10.57 8.74 1.59 11.25 9.45 1.61 11.92 9.41 1.62 12.60 10.03 1.64
19.4 9.13 7.77 1.79 10.16 7.82 1.81 10.86 8.51 1.83 11.55 9.20 1.85 12.25 9.17 1.87 12.94 9.77 1.88
25 9.46 8.09 2.13 10.54 8.13 2.16 11.26 8.86 2.19 11.98 9.58 2.20 12.70 9.55 2.23 13.42 10.17 2.25
30 9.94 8.15 3.20 11.07 8.19 3.25 11.83 8.93 3.28 12.58 9.65 3.31 13.34 9.62 3.34 14.09 10.25 3.38
35 9.72 8.09 3.52 10.83 8.14 3.58 11.57 8.87 3.61 12.31 9.59 3.65 13.05 9.55 3.68 13.79 10.17 3.72
40 8.93 7.63 3.63 9.95 7.68 3.68 10.63 8.37 3.72 11.31 9.05 3.75 11.98 9.01 3.79 12.66 9.60 3.83
46.1 7.26 6.71 3.11 8.09 6.75 3.16 8.64 7.35 3.19 9.19 7.94 3.22 9.74 7.91 3.26 10.30 8.43 3.29
- 20 -
4-1. Cooling capacity 4. Capacity table
DUCT TYPE ARU12-48RGLX DUCT TYPE ARU12-48RGLX

Fujitsu AOU24RGLX Specifications

General

Brand	Fujitsu
Model	AOU24RGLX
Category	Air Conditioner
Language	English
