Evaporator Total Assy61
Water Seal63
Evaporator Holder R64
Evaporator Holder L
Parts number
DescriptionRef
9315251015
9314994012
65
Rear bracket
66
67
Filter Guide
Filter Guard
62 Connection Pipe Assy
9314995019
9315013019
9315411013
68 Pipe Thermistor 9900551018
9315338020
9315355010
2014.10.29
INDOOR UNIT
Evaporator
67
66
64
62
63
61
68
65
12
