- 12 -
WALL MOUNTED
ASU30RLE
3. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASU30RLE
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 8.79
Btu/h 30,000
Min.—Max.
kW 2.9—9.5
Btu/h 9,900—32,400
Heating
Rated
kW 9.37
Btu/h 32,000
Min.—Max.
kW 2.35—11.0
Btu/h 8,000—36,200
Input power
Cooling
Rated
kW
2.40
Min.—Max. 0.58—3.83
Heating
Rated 2.74
Min.—Max. 0.50—4.28
Fan
HIGH
W
60
MED 35
LOW 20
QUIET 11
Current
Cooling
Rated A
10.6
Heating 12.0
EER Cooling
kW/kW 3.66
Btu/hW 12.5
COP Heating
kW/kW 3.42
Btu/hW 11.7
SEER Cooling Btu/hW 18.7
HSPF Heating Btu/hW 11.8
Power factor
Cooling
%
99.6
Heating 99.2
Moisture removal pints/h (L/h) 9.7 (4.6)
Maximum operating current *1
Cooling
A
20.5
Heating 20.5
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
812 (1,380)
MED 665 (1,130)
LOW 536 (910)
QUIET 418 (710)
Heating
HIGH 812 (1,380)
MED 665 (1,130)
LOW 536 (910)
QUIET 418 (710)
Type × Q'ty Cross flow fan × 1
Motor output W 80
Sound pressure level *2
Cooling
HIGH
dB (A)
50
MED 45
LOW 38
QUIET 32
Heating
HIGH 49
MED 44
LOW 38
QUIET 32
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main: 18-3/16 × 35-7/16 × 1-1/16 (462 × 900 × 26.6)
Sub1: 4-15/16 × 35-7/16 × 17/32 (126 × 900 × 13.3)
Sub2: 3-5/16 × 35-7/16 × 17/32 (84 × 900 × 13.3)
Fin pitch FPI 1.2
Rows × Stages Main: 2 × 22, Sub1: 1 × 6, Sub2: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in 13-6/16 × 45-4/16 × 9
mm 340 × 1,150 × 280
Gross
in 17-11/16 × 50 × 15-15/16
mm 450 × 1,270 × 405
Weight
Net
lb (kg)
40 (18)
Gross 53 (24)
Connection pipe
Size
Liquid
in (mm)
Ø3/8 (Ø9.52)
Gas Ø5/8 (Ø15.88)
Method Flare
Drain hose
Material PVC
Size in (mm) Ø9/16 (Ø13.8) (I.D.), Ø10/16 to Ø11/16 (Ø15.8 to Ø16.7) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 88 (30) or less
