CASSETTE TYPE AUU42R
CASSETTE TYPE AUU42R
- (04 - 08) -
MOUNTING POSITION
3-15/16 (100)
or more
3-15/16 (100)
or more
3-15/16 (100)
or more
3-15/16 (100) or more
(4 directions) (3 directions)
Piping position
(2 directions) (2 directions)
You can select 2-way setting
(A) Standard setting (B) Slender setting
39-3/8 (1,000)
or more
Strong and durable ceiling
47-1/4 (1,200)
or more
96 (2,400)
or more
Obstruction
11-13/16 (300)
or more
10-7/16 (265)
or more
Floor
Unit : in.(mm)
