INDOOR UNIT
Control box
17
Terminal 9900720001
Main PCB (09) 9709427095
13
Earth terminal
Control Box11
Cover shield
9332892024
Box shield assy
12
Main PCB (12) 970942710112
15
Room Thermistor Holder
9332868005
Ref. Description Part number
14
-- Thermistor Assy 9900714024
Display Assy 9709430019
2013.11.12
