Fujitsu AOU9RLFW1 - Outdoor Unit Aou12 Rlfw1

OUTDOOR UNIT
AOU12RLFW1
2013.11.14 22
2 Top Panel Assy 9317761024
3 Front Panel Assy 9317760034
1 Protective Net 9313941048
5
6
Cabinet Left Assy 9318247008
4 Emblem 9332356014
Switch Cover 9313940027
Valve
bracket
7 Cabinet Right Assy 9313994129
Valve
bracket
cover
Motor bracket
9 Propeller Fan 9313808013
10 Reactor Assy 9900611019
Separator
assy
8 Fan Motor 9602864003
Ref. Description Part number
3
4
5
10
9
8
1
6
7
2
Terminal
bracket
13 Terminal 5P 9703874055
Inverter
case cover
Terminal
cover
Bracket
conduit
Main PCB
Sealed panel
Inverter case assy
11 9708523057
12 PCB Holder 9313074029
16 Heatsink B 9314090011
Semiconductor Accessory 14 9705840010
15 Heatsink A 9314410017
12
11
14
16
15
13
