2013.10.29
2
OUTDOOR UNIT
AOU9RLFW1
AOU12RLFW1
26 inch (660 mm)
17-3/4 inch (454 mm)
21-1/4 inch (540 mm)
1
1-7/16 (290)
21-1/4 inch (540 mm)
1
1-7/16 (290)
31-1/8 in. (790 mm)
21-1/4 inch (540 mm)
DIMENSIONS
10-9/16 inch
(268 mm)
5/8 to 11/16
(15.8 to 16.7)
8 inch
(203 mm)
33-1/16 inch (840 mm)
INDOOR UNIT
Drain hose
Diameter
Outside
Inside : 9/16 inch
(13.8 mm)
23-5/8 inch (600 mm)
2
4
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Indoor Unit
1
Outdoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
7
Outdoor Pcb Circuit Diagram
11
Outdoor Unit Aou9Rlfw1 Circuit Diagram
12
Error Detection
15
Parts (Indoor Unit)
17
INDOOR UNIT Casing Assy
20
Parts (Outdoor Unit)
21
Outdoor Unit Aou12Rlfw1
23
Indoor Unit/Optional Parts
25
Accessories
25
