Fujitsu AOU9RLFW1 Service Manual

SPECIFICATIONS
TYPE Cool & heat inverter
INDOOR UNIT ASU12RLF1
OUTDOOR UNIT AOU12RLFW1
COOLING CAPACITY 12,000 Btu/h
HEATING CAPACITY 16,000 Btu/h
POWER SOURCE 208/230 V
FREQUENCY 60 Hz
RUNNING
CURRENT
MAXIMUM
CURRENT
4.4 A
5.9 A
INPUT WATTS
0.960 kW
1.280 kW
E.E.R. Cooling 12.50 Btu/Wh
COP Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
12.50 Btu/Wh
MOISTURE REMOVAL 3.80 Pts/h (1.8 L/h)
AIR CIRCULATION
ASU9RLF1
AOU9RLFW1
9,000 Btu/h
12,000 Btu/h
208/230 V
60 Hz
3.2 A
4.2 A
6.5 A
9.0 A
6.0 A
7.5 A
0.650 kW
0.890 kW
13.80 Btu/Wh
13.50 Btu/Wh
2.75 Pts/h (1.3 L/h)
441 cfm (750 m
3
/h) 441 cfm (750 m
3
/h)
FAN MOTOR
POWER SOURCE 230 V 230 V
High
INDOOR UNIT
Cooling
Medium
Low
Quiet
High
INDOOR UNIT
Heating
Medium
Low
Quiet
High
Medium
Low
Quiet
1,320 r.p.m.
1,160 r.p.m.
930 r.p.m.
680 r.p.m.
1,320 r.p.m.
1,160 r.p.m.
980 r.p.m.
710 r.p.m.
OUTDOOR UNIT Heating 720 r.p.m.
OUTDOOR UNIT Cooling 780 r.p.m.
1,320 r.p.m.
1,160 r.p.m.
930 r.p.m.
680 r.p.m.
1,320 r.p.m.
1,160 r.p.m.
980 r.p.m.
710 r.p.m.
680 r.p.m.
780 r.p.m.
ELECTRICAL DATA
INDOOR UNIT
Cooling
High
Medium
Low
Quiet
INDOOR UNIT
Heating
OUTDOOR UNIT Heating
NOISE LEVEL
43 dB
40 dB
32 dB
21 dB
43 dB
38 dB
33 dB
22 dB
43 dB
40 dB
32 dB
21 dB
43 dB
38 dB
33 dB
22 dB
48 dB 49 dB
OUTDOOR UNIT Cooling 48 dB 49 dB
2013.11.25 1
COMPRESSOR TYPE
Hermetic type, 4 pole,
DC inverter motor, Rotary
DISCRIMINATION DA89X1C-20FZ2
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R410AR410A
WEIGHT (with oil)
COMPRESSOR AND REFRIGERANT
Pipe length
FULL CHARGE
MAXIMUM PIPING HEIGHT
ADDITIONAL CHARGE
WEIGHT
INDOOR UNIT Net / Shipping
Net / Shipping
18.7 lb / 23.2 lb (8.5 kg / 10.5 kg)
OUTDOOR UNIT
79.5 lb / 86.1 lb
(36 kg / 39 kg)
59.6 lb / 66.2 lb
(27 kg / 30 kg)
INDOOR UNIT H x W x D
H x W x DOUTDOOR UNIT
DIMENSIONS
10-9/16 x 33-1/16 x 8 inch (268 x 840 x 203 mm)
37.0 oz (1,050 g)
37.0 oz (1,050 g)
20.3 lb (9.2 kg)
49 ft (15 m)
66 ft (20 m) 40.6 oz (1,150 g)
49 ft (15 m)
0.21 oz/ft (20 g/m)
5SS072XAA
30.0 oz (850 g)
30.0 oz (850 g)
13.0 lb (5.9 kg)
33.5 oz (950 g)
21-1/4 x 25-31/32
x 11-13/32 inch
(540 x 660 x 290 mm)
21-1/4 x 31-3/32
x 11-13/32 inch
(540 x 790 x 290 mm)
E.E.R. Cooling
12.50 BTU/Wh
(3.66 kW/kW)
COP Heating
12.50 BTU/Wh
(3.66 kW/kW)
13.80 BTU/Wh
(4.05 kW/kW)
13.47 BTU/Wh
(3.95 kW/kW)
