Page #9 background imageLoading...
Page #9 background image
1
2
3
4
5
6
7
2
1
3
VCC
OUT
GND
I C201
GP1UM261R
JM1
C203
0.1
<B>
+
C202
47/
10V
R202
47
<1/4W>
5V
A
A
A
SW201
KSHC611BT
5V
CN201
S7B-PH-K-S
D201 SL I-343 GREEN
D202 SL I-343 ORANGE
D203 SL I-343 GREEN
5V
2013.10.23 8
INDOOR UNIT
INDICATOR PCB
K12JZ-1200HSE-D0
