Item no. Part no. Part name Service part

1 9323351004 Bracket panel ♦

2 9387476002 Screw cover ♦

3 9313951047 Conduit holder ♦

4 9383729027 Wire cover B ♦

5 9387597035 Wire cover assy ♦

6 9383765032 WLAN adapter holder assy ♦

7 9383634017 Wireless LAN adapter ♦

8 9387479010 Horizontal louver assy ♦

9 9332911008 Electric filter holder ♦

10 9323341005 Under cover L ♦

11 9317250009 Air clean filter assy ♦

12 9332438765 Remote controller ♦

13 9318912005 Remote controller holder ♦

14 9387596601 Front panel total assy ♦

15 9387756210 Intake grille assy ♦

16 9323340008 Air filter ♦

17 9333719009 Grille clamper L ♦

18 9333704005 Grille clamper R ♦

19 9323342002 Under cover R ♦

20 9383730030 Louver spring ♦

21 9333608006 Bush ♦

— 9901010019

Wire with connector

(CN6 on main PCB—WLAN adapter)

♦

a — Front panel —

b — Panel cover —

c — Front panel cover —

d — Front panel B —

2-1. Models: ASUG09LZAS, ASUG12LZAS, and ASUG15LZAS - (02-3) - 2. Indoor unit parts list
