Item no. Part no. Part name Service part

1 9322556028 Top panel assy ♦

2 9377854001 Protective net assy ♦

3 9322327000 Thermistor holder ♦

4 9322552242 Cabinet right assy ♦

5 9384276001 Conduit cover ♦

6 9322570062 Switch cover assy ♦

7 9901059025 Heater base ♦

8 9323540019 Heater holder A ♦

9 9323541016 Heater holder B ♦

10 9383720000 Drain cap assy ♦

11 9323550025 Base assy ♦

12 9322144003 Drain pipe ♦

9709684009 Main PCB (for 09 model) ♦

9709684016 Main PCB (for 12 model) ♦

9709684023 Main PCB (for 15 model) ♦

14 9900935054 Thermistor assy ♦

15 9900985011 Thermistor assy (Compressor temp.) ♦

16 9900565060 Thermistor assy (Outdoor temp.) ♦

17 9322420039 Heat sink ♦

18 9810028006 Thermistor stopper ♦

19 9317903011 Emblem ♦

20 9384273000 Fan Guard ♦

21 9322555182 Front panel assy ♦

22 9322150004 Propeller fan ♦

23 9603601003 Brushless motor ♦

24 9322553027 Motor bracket assy ♦

9317089616 Condenser total assy (for 09-12 model) ♦

9317089654 Condenser total assy (for 15 model) ♦

a — Inverter assy —

b — Hair pin cushion —

3-1. Models: AOUG09LZAH1, AOUG12LZAH1, and AOUG15LZAH1 - (02-7) - 3. Outdoor unit parts list
