33
40
39
34
32
31
36
37
35
INDOOR UNIT
Control box
15
36
Terminal 9900638009
Main PCB (07) 9708713281
35
Earth Terminal 9318918007
31
Control Box
9318916003
32
Cover Shield A
9318882049
33 Box Shield Assy 9319344010
34
Main PCB (09) 970871329834
40 Step Motor 9900384166
37
Room Thermistor Holder
9319068008
39 Gear Cover 9318902006
Ref. Description Part number
47
Display PCB 970882401748
38 Thermistor Assy 9900627003
Display Assy 9708823010
45 Grille Key Top 9319334004
46 Micro Switch 9900625009
42 Panel Gear 9319293004
Switch Case 9319332000
43
44
Gear Case 9318903003
41 Gear B 9319294001
2012.11.20
43
44
41
42
45
46
47
48
38
