8-3. Setting of external input and output
• Indoor unit
Input
Connection point Function setting number 46 Function
CN46
00 Operation/Stop mode 1 (R.C. enabled)
01 (Setting prohibited)
02 Forced stop mode
03 Operation/Stop mode 2 (R.C. disabled)
Output
Connection point Function setting number 60 Function
CN47
00 Operation status
01 to 08 (Setting prohibited)
09 Error status
10 Indoor unit fan operation status
11 (Setting prohibited)
• External input and output PCB
Switch setting Input Output
Rotary
switch
SW302 CN313 CN314 CN310 CN311 CN312
1
Edge Operation/Stop Not available
Operation
status
Error status
Indoor unit fan
status
Pulse Operation Stop
2
Edge*
Forced
thermostat off
Not available Error status
Indoor unit fan
operation
status
Not available
3 to 9, A (Setting prohibited)
B
Forced
thermostat off
Not available
Operation
status
Indoor unit fan
operation
status
Not available
C
Forced
thermostat off
Not available
Operation
status
Error status Not available
D (Setting prohibited)
NOTES:
• When the rotary switch is selected to “1”, the operation of the connector input of the indoor
unit and the External input and output PCB input are the same. The operation content de-
pends on the setting of function setting number 46.
• *: The external input other than “Operation/Stop” is available only when the SW302 is set to
“Edge”.
- 26 -
8-3. Setting of external input and output
8. External input and output
WALL MOUNTED ASYG07-14KGT WALL MOUNTED ASYG07-14KGT

Fujitsu AOYG09KGCA Specifications

General

Type	Air conditioner outdoor unit
Multi-split	-
Product color	White
Inverter technology	Yes
Refrigerating medium	R32
Dehumidifying capacity	1.3 l/h
Air conditioner functions	Circulation, Cooling, Dehumidifying, Fan, Heating, Ventilating
Refrigerating medium weight	750 g
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	4.5
Heating energy efficiency (COP, W/W)	5
Seasonal efficiency rating (cooling) (SEER)	8.52
Seasonal efficiency rating (heating) (SCOP)	5.11
Current (cooling)	6.5 A
Current (heating)	9 A
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	2.5 kWh
Hourly energy consumption (heating)	2.8 kWh
Design load (heating) (Warmer heating season)	2.4 kW
Design load (heating) (Average heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Warmer heating season)	658 kWh
Annual energy consumption (heating) (Average heating season)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	799 mm
Outdoor unit height	542 mm
Outdoor unit weight	30000 g
Outdoor units quantity	1
Outdoor unit noise level	63 dB
Cooling airflow (outdoor unit)	1610 m³/h
