PARTS
2
1
3
6
9
7
8
12
11
10
13
4
4
5
5
INDOOR UNIT
Front panel
2011.01.24
13
5
Air Filter
9316562004
2
Front Panel
9316558045
6
Receiver Window
9316588011
4
9
Grille Clamper
9316906006
3
Intake Grille Assy
9332272055
Panel Cover
9316561014
1
Front Panel Total Assy
9316897342
7
Wire Cover
9316559004
8
Wire Shield
9316584006
--
Air Clean Filter Assy
9317250009
12
Remote Control
9319208008
13
Remote Control Holder
9318912005
Ref.
Description
Part number
11
Louver U
9316572003
10
Louver Z
9316573000
13
15
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
R202 C203
8
Outdoor Pcb Circuit Diagram
10
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
18
Accessories
21
