INDOOR UNIT
Evaporator
Fan
Fan Motor 9603269005
Crossflow Fan Assy 9316830004
Bearing C Assy 9306628017
35
32
Evaporator Total Assy 933298900731
Casing Assy 9333009001
33
34
Ref. Description Part number
142013.02.27
35
34
33
31
32
