Page #13 background imageLoading...
Page #13 background image
32
31
35
INDOOR UNIT
ASYG07LMCE
ASYG09LMCE
Control box
12
Terminal 990072000133
Earth Terminal
Control Box31
Cover Shield
9332892000
Box Shield Assy
Main PCB (ASYG07LMCE)
970942703332
Main PCB (ASYG09LMCE)
970942701932
35 Room Thermistor Holder 9332868005
Ref. Description Part number
34
-- Thermistor Assy 9900930011
Display Assy 9709430019
2016.11.09
34
33
