Fujitsu AOYG12KATA - Page 22

¢
Model: AUXG22KVLA
AFR
m
3
/h
860
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.60 2.16 5.46 2.21 5.33 2.25 5.20 2.30 5.06 2.34
-10 -11 6.14 2.25 6.00 2.29 5.85 2.34 5.70 2.39 5.56 2.43
-5 -7 6.70 2.32 6.54 2.37 6.38 2.42 6.22 2.47 6.06 2.52
0 -2 7.26 2.40 7.08 2.45 6.91 2.50 6.74 2.55 6.56 2.60
5 3 7.81 2.48 7.63 2.53 7.44 2.58 7.25 2.63 7.07 2.68
7 6 8.40 2.48 8.20 2.53 8.00 2.58 7.80 2.63 7.60 2.68
10 8 8.05 2.34 7.86 2.39 7.67 2.44 7.48 2.49 7.29 2.54
15 10 7.49 2.11 7.31 2.16 7.13 2.20 6.95 2.24 6.77 2.28
20 15 7.04 1.80 6.87 1.83 6.70 1.87 6.53 1.91 6.37 1.94
24 18 7.32 1.78 7.14 1.81 6.97 1.85 6.80 1.89 6.62 1.92
- 12 -
4-2. Heating capacity
4. Capacity table
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA
