Fujitsu AOYG18KBTA2 User Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
0.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
15.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
20.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
25.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
30.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
35.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
40.0 1.85 1.18 2.10 1.35 2.21 1.55 2.37 1.75 2.53 1.91 2.61 2.19
46.0 1.75 1.05 1.98 1.20 2.08 1.38 2.23 1.55 2.38 1.70 2.46 1.95
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 2.37 1.50 2.68 1.71 2.83 1.96 3.03 2.21 3.24 2.41 3.34 2.76
46.0 2.24 1.33 2.53 1.52 2.67 1.75 2.86 1.96 3.05 2.15 3.15 2.46
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
0.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
5.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
10.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
15.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
20.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
25.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
30.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
35.0 2.87 1.89 3.24 2.15 3.42 2.48 3.66 2.78 3.91 3.04 4.03 3.49
40.0 2.72 1.69 3.07 1.93 3.23 2.22 3.46 2.49 3.70 2.72 3.82 3.12
46.0 2.56 1.50 2.89 1.71 3.05 1.97 3.27 2.22 3.49 2.42 3.60 2.78
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
0.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
5.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
10.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
15.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
20.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
25.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
30.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
35.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
40.0 2.87 1.69 3.24 1.93 3.42 2.22 3.66 2.49 3.91 2.73 4.04 3.13
46.0 2.71 1.50 3.06 1.72 3.23 1.97 3.45 2.22 3.69 2.43 3.81 2.78
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 311 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG18KBTA2 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA2
Category	Air Conditioner
Language	English
