Fujitsu AOYG18KBTA2 User Manual


Mini duct type
Model: ARXG07KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.54 0.84 1.74 0.96 1.84 1.10 1.97 1.24 2.10 1.35 2.17 1.55
46.0 1.12 0.45 1.27 0.51 1.34 0.59 1.43 0.66 1.53 0.72 1.58 0.83
Model: ARXG09KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
0.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
5.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
10.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
15.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
20.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
25.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
30.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
35.0 2.51 1.61 2.84 1.83 2.99 2.11 3.20 2.37 3.42 2.59 3.53 2.97
40.0 1.97 0.99 2.23 1.13 2.35 1.31 2.52 1.47 2.69 1.60 2.78 1.84
46.0 1.44 0.53 1.63 0.60 1.72 0.69 1.84 0.78 1.96 0.85 2.02 0.98
Model: ARXG12KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
0.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
5.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
10.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
15.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
20.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
25.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
30.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
35.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
40.0 2.26 1.14 2.55 1.30 2.69 1.49 2.88 1.68 3.08 1.83 3.17 2.10
46.0 1.65 0.60 1.86 0.69 1.96 0.79 2.10 0.89 2.25 0.98 2.31 1.12
Model: ARXG14KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
0.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
5.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
10.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
15.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
20.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
25.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
30.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
35.0 3.03 1.86 3.43 2.12 3.61 2.45 3.87 2.75 4.14 3.01 4.26 3.44
40.0 2.39 1.15 2.70 1.32 2.84 1.51 3.05 1.70 3.26 1.86 3.36 2.13
46.0 1.74 0.61 1.97 0.70 2.07 0.81 2.22 0.91 2.37 0.99 2.45 1.13
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 312 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG18KBTA2 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA2
Category	Air Conditioner
Language	English
