Fujitsu AOYG18KBTA2 User Manual


Slim duct type
Model: ARXG07KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.54 0.84 1.74 0.96 1.84 1.10 1.97 1.24 2.10 1.35 2.17 1.55
46.0 1.12 0.45 1.27 0.51 1.34 0.59 1.43 0.66 1.53 0.72 1.58 0.83
Model: ARXG09KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 1.97 1.03 2.23 1.18 2.35 1.36 2.52 1.53 2.69 1.67 2.78 1.91
46.0 1.44 0.55 1.63 0.63 1.72 0.72 1.84 0.81 1.96 0.89 2.02 1.02
Model: ARXG12KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
0.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
5.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
10.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
15.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
20.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
25.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
30.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
35.0 2.87 1.94 3.24 2.21 3.42 2.54 3.66 2.85 3.91 3.12 4.03 3.58
40.0 2.26 1.20 2.55 1.37 2.69 1.57 2.88 1.77 3.08 1.93 3.17 2.22
46.0 1.65 0.64 1.86 0.73 1.96 0.84 2.10 0.94 2.25 1.03 2.31 1.18
Model: ARXG14KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
0.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
5.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
10.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
15.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
20.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
25.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
30.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
35.0 3.03 1.94 3.43 2.21 3.61 2.55 3.87 2.86 4.14 3.13 4.26 3.59
40.0 2.39 1.20 2.70 1.37 2.84 1.58 3.05 1.77 3.26 1.94 3.36 2.22
46.0 1.74 0.64 1.97 0.73 2.07 0.84 2.22 0.94 2.37 1.03 2.45 1.18
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 313 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG18KBTA2 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA2
Category	Air Conditioner
Language	English
