En-13
8.1.1 System diagram
One WLAN adapter can be connected to each indoor unit.
CBA
Single connection
Outdoor unit Outdoor unit
Indoor unit
Indoor unit
Indoor unit
WLAN adapter WLAN adapter WLAN adapter
Multi-split connection
A, B, and C are adapter cables attached to this product.
Prohibited uses:
(1) Group connection of indoor units with wired remote controller
3 wire
3-wire
remote
controller
2-wire
remote
controller
2 wire
Indoor unit Indoor unit Indoor unit Indoor unit
WLAN adapter
WLAN adapter
