Fujitsu AP-WJ4E - Page 14

En-14
(2) Group connection of indoor units
3 wire
2 wire
Indoor unit Indoor unit Indoor unit Indoor unit
(3) Group connection of indoor units
with WLAN adapter cable.
(4) Extended wiring
Extending the cable is prohibited.
Indoor unit Indoor unit
Adapter cable
Junction box
Indoor unit
Junction box
WLAN adapter
WLAN adapterWLAN adapter WLAN adapter
WLAN adapter
WLAN adapter
