Fujitsu AR-90T - Page 6

– 5 –
(Unit : mm)
HOOK METAL
CONTROL BOX
SAFETY DRAIN PORT
AIR FLOW OUTLET AIR FLOW INLET
COUPLING PIPE
MAIN DRAIN PORT
38.1 (DRAIN PIPE)
LIQUID : 12.7 FLARE
GAS : 28.58 FLANGE
1,550 (MAXIMUM)
1,450
713 (MAXIMUM)
600
450
25.4 (SAFETY DRAIN)
