Fujitsu AR*9LUAB

- (01 - 21) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
(Unit : mm)
MODELS : AS 7L, AS 9L, AS 12L
MODEL : AS 18L
257
808
Front view Side view
Front view
Side view
187
MOUNTING POSITION
1500 mm
or over
2300 mm or over
Right side
50 mm or over
Left side
50 mm or over
60 mm or over
1,120
626
711
320
220
4-4. WALL MOUNTED MODEL
