MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
4-1. DUCTED MODEL
MODELS : AR 9L, AR 12L, AR 14L, AR 18L
(Unit : mm)
( ) : AR 9L
886(596)
953(663)
850(560)
920(630)
600(400)
150
150
595
57520
85 75
364
390
194
217
BRACKETS
AIR FLOW OUTLET
CONTROL BOX
COUPLING PIPE ASSY
DRAIN PORT
1
Refrigerant piping flare connection (Gas)
Refrigerant piping flare connection (Liquid)
Drain piping connection
2
3
12
3
1
2
Top view
Front view
Side view
4. DIMENSIONS
