Fujitsu AS*12LMACW - Mounting Position Guidelines

- (01 - 16) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
MOUNTING POSITION
MAINTENANCE HOLE
(Unit : mm)
Left
side
Right
side
100 or more
300 or more
Strong and durable ceiling
Indoor unit
Left
side
Right side
(PIPE side)
Strong and durable floor
100 or more 300 or more
30
or more
30
or more
Maintenance hole
Unit
100
or more
Control box
300
or more
