6. CAPACITY TABLE
6-1. COMBINATIONS
MODEL : AO 18L2
COOLING
HEATING
Room 1 Room 2 Total Room 1 Room 2 Room 1 Room 2 Min. Rated Max. Min. Rated Max.
Min. 14 kBTU 7 7 14 2.20 2.20 2.50 2.50 2.00 4.40 5.00 0.68 1.41 1.71 3.12 B
Max. 24 kBTU 7 9 16 2.30 2.80 2.48 3.02 2.00 5.10 5.50 0.68 1.70 1.86 3.00 C
7 12 19 2.05 3.25 2.28 3.62 2.00 5.30 5.90 0.68 1.73 2.07 3.06 B
7 14 21 1.90 3.50 2.25 4.15 2.00 5.40 6.40 0.68 1.73 2.22 3.12 B
9 9 18 2.70 2.70 3.00 3.00 2.00 5.40 6.00 0.68 1.73 2.08 3.12 B
9 12 21 2.40 3.00 2.84 3.56 2.00 5.40 6.40 0.68 1.72 2.22 3.14 B
9 14 23 2.20 3.30 2.60 3.90 2.00 5.50 6.50 0.68 1.73 2.22 3.18 B
12 12 24 2.70 2.70 3.20 3.20 2.00 5.40 6.40 0.68 1.70 2.22 3.18 B
Cooling capacity
for each indoor
unit Rated (kW)
Total cooling capacity (kW)
Total Input (kW)
Cooling capacity
for each indoor
unit Max (kW)
Indoor model for each room
705
850
865
865
Annual energy
consumption
(KW/h)
EER
(kW/kW)
Class
865
860
865
850
Room 1 Room 2 Total Room 1 Room 2 Room 1 Room 2 Min. Rated Max. Min. Rated Max.
Min. 14 kBTU 7 7 14 2.60 2.60 3.20 3.20 2.20 5.20 6.40 0.68 1.57 2.13 3.31 C
Max. 24 kBTU 7 9 16 2.80 3.40 3.07 3.73 2.20 6.20 6.80 0.68 2.06 2.22 3.01 D
7 12 19 2.45 3.75 2.69 4.11 2.20 6.20 6.80 0.68 1.93 2.22 3.21 C
7 14 21 2.30 4.00 2.56 4.44 2.50 6.30 7.00 0.75 1.85 2.22 3.41 B
9 9 18 3.15 3.15 3.50 3.50 2.20 6.30 7.00 0.68 1.95 2.22 3.23 C
9 12 21 2.80 3.50 3.11 3.89 2.20 6.30 7.00 0.75 1.90 2.22 3.32 C
9 14 23 2.60 3.80 2.88 4.22 2.50 6.40 7.10 0.75 1.84 2.22 3.48 B
12 12 24 3.15 3.15 3.50 3.50 2.20 6.30 7.00 0.75 1.88 2.22 3.35 C
Indoor model for each room
Heating capacity
for each indoor
unit Rated (kW)
Total heating capacity (kW)
Total Input (kW)
Heating capacity
for each indoor
unit Max (kW)
Annual energy
consumption
(KW/h)
COP
(kW/kW)
Class
785
1030
965
925
975
950
920
940
NOTES
Cooling capacity is based on 27 °CDB /19 °CWB (indoor temperature),35 °CDB (outdoor temperature).
Heating capacity is based on 20 °CDB (indoor temperature),7 °CDB/6 °CWB (outdoor temperature)
It is impossible to connect the indoor unit for one room only.
The total capacity of connected a indoor unit is up to 24000BTU from 14000BTU.
