Fujitsu AS*12LMACW User Manual

- (01 - 05) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
Display panel
FUNCTIONS
DIMENSION
SPECIFICATION
Display
13
12
11
10
9
2
1
3
5
6
4
7
8
DAY OFF
DELETE SET
ENERGY
SAVE
SET BACK
DAY
CLOCK ADJUST
SU MO TU WE TH FR SA
369 12 15 18 21
THERMO
SENSOR
15
14
1617 18
1920
SU MO TU WE TH FR SA
369 12 15 18 21
120
120
17
Front View
DAY OFF
DELETE SET
ENERGY
SAVE
SET BACK
DAY
CLOCK ADJUST
SU MO TU WE TH FR SA
369 12 15 18 21
THERMO
SENSOR
[ Unit : mm ]
SIZE (H x W x D mm) 120 x 120 x 17
WEIGHT ( g ) 160
CABLE LENGTH ( m )
POWER ( V )
10
12
Set temperature button
7
6
1
START/STOP button
Pressed to start and stop operation.
17
Operation mode display
13
Operation lamp
Lights during operation and when the timer is on.
5
Energy save button
Turns the energy efficient mode on and off.
8
Day (DAY OFF) button
14
Timer and clock display
12
Set button
Sets the date, hour, minute and on-off time.
9
Set back button
Central control display
10
Timer mode (CLOCK ADJUST) button
Thermo sensor
Set time button
Pressed to set time.
Master control button
Selects the operating mode(AUTO, HEAT, FAN, COOL, DRY).
4
3
Fan control button
Selects the fan speed (AUTO, LOW, MED, HIGH).
18
Temperature display
16
Fan speed display
15
20
Energy save display
19
Stand by display
Indicates during defrosting operation.
Temporarily cancels of one day timer.
2
11
Delete button
Selects the setting temperature.
Selects the timer mode (OFF TIMER, ON TIMER, WEEKLY TIMER)
Pressed select the set back timer.
The schedule of a weekly timer is deleted.
Set the current time.

Fujitsu AS*12LMACW Specifications

General

Brand	Fujitsu
Model	AS*12LMACW
Category	Air Conditioner
Language	English
