- (01 - 20) -
MULTI TYPE
2ROOM TYPE
MULTI TYPE
2ROOM TYPE
Ceiling
Left
Indoor unit
Right
Ceiling
150 or more 300 or more
20 or more
1000 or more
2300 or more
Left Right
300 or more300 or more
MOUNTING POSITION
Obstruction
Floor
(Unit : mm)
