Fujitsu AS*12LMACW User Manual

- (01 - 33) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
MODEL : AO 24L2
INDOOR UNIT : 12000BTU + 14000BTU
INDOOR UNIT : 12000BTU + 18000BTU
INDOOR UNIT : 14000BTU + 14000BTU
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
PI : Power Input (kW)
°CDB
°CWB
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 4.91 4.43 0.55 5.47 4.46 0.56 5.66 4.85 0.57 6.03 4.87 0.57 6.22 5.25 0.57 6.59 5.24 0.58 6.78 5.23 0.58 6.96 5.57 0.59
5 4.91 4.43 0.66 5.47 4.46 0.67 5.66 4.85 0.67 6.03 4.87 0.68 6.22 5.25 0.68 6.59 5.24 0.69 6.78 5.23 0.69 6.96 5.57 0.69
10 4.70 4.33 0.79 5.24 4.36 0.80 5.41 4.74 0.80 5.77 4.76 0.81 5.95 5.14 0.82 6.31 5.12 0.82 6.49 5.11 0.83 6.66 5.45 0.83
15 5.36 4.53 1.26 5.97 4.56 1.28 6.17 4.95 1.29 6.58 4.97 1.30 6.78 5.37 1.31 7.19 5.35 1.32 7.39 5.34 1.33 7.59 5.69 1.34
20 5.52 4.49 2.17 6.15 4.52 2.20 6.36 4.91 2.21 6.78 4.93 2.24 6.99 5.32 2.25 7.41 5.30 2.27 7.62 5.29 2.28 7.83 5.65 2.29
25 5.64 4.54 2.09 6.28 4.57 2.12 6.49 4.96 2.14 6.92 4.98 2.16 7.13 5.38 2.17 7.56 5.36 2.19 7.78 5.35 2.20 7.99 5.71 2.21
30 5.75 4.58 2.27 6.40 4.61 2.31 6.62 5.01 2.32 7.06 5.03 2.34 7.28 5.43 2.35 7.71 5.41 2.38 7.93 5.40 2.39 8.15 5.77 2.40
35 5.85 4.63 2.67 6.51 4.65 2.77 6.73 5.06 2.77 7.18 5.08 2.77 7.40 5.48 2.77 7.84 5.46 2.77 8.07 5.45 2.77 8.29 5.82 2.77
40 5.26 4.38 2.67 5.86 4.41 2.77 6.06 4.79 2.77 6.46 4.81 2.77 6.66 5.19 2.77 7.06 5.17 2.77 7.26 5.16 2.77 7.46 5.51 2.77
43 4.38 3.99 2.27 4.88 4.02 2.35 5.05 4.37 2.35 5.38 4.38 2.35 5.55 4.73 2.35 5.88 4.72 2.35 6.05 4.71 2.35 6.22 5.02 2.35
12+14
Outdoor temperature
32°CDB
16°CWB
18°CWB
Indoor temperature
18°CDB
21°CDB
23°CDB
25°CDB
27°CDB
29°CDB
30°CDB
19°CWB
21°CWB
22°CWB
23°CWB
12°CWB
15°CWB
°CDB
°CWB
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 5.75 4.75 0.75 6.41 4.78 0.76 6.62 5.19 0.76 7.06 5.21 0.77 7.28 5.63 0.78 7.72 5.60 0.78 7.94 5.59 0.79 8.15 5.97 0.79
5 5.75 4.75 0.89 6.41 4.78 0.90 6.62 5.19 0.91 7.06 5.21 0.92 7.28 5.63 0.92 7.72 5.60 0.93 7.94 5.59 0.94 8.15 5.97 0.94
10 5.50 4.64 1.02 6.13 4.67 1.03 6.34 5.08 1.04 6.76 5.10 1.05 6.97 5.50 1.05 7.39 5.48 1.06 7.60 5.47 1.07 7.80 5.84 1.07
15 5.83 4.78 1.41 6.49 4.81 1.43 6.71 5.23 1.44 7.15 5.25 1.45 7.37 5.66 1.46 7.82 5.64 1.48 8.04 5.63 1.48 8.26 6.01 1.49
20 6.47 5.05 2.67 7.21 5.09 2.77 7.45 5.53 2.77 7.94 5.55 2.77 8.19 5.99 2.77 8.68 5.97 2.77 8.93 5.96 2.77 9.17 6.36 2.77
25 7.07 5.33 2.58 7.88 5.36 2.62 8.15 5.83 2.64 8.68 5.85 2.66 8.95 6.32 2.68 9.49 6.29 2.77 9.76 6.28 2.77 10.03 6.70 2.77
30 6.73 5.17 2.55 7.50 5.20 2.59 7.75 5.65 2.60 8.27 5.68 2.63 8.52 6.13 2.64 9.03 6.11 2.67 9.29 6.09 2.68 9.54 6.50 2.70
35 6.16 4.92 2.67 6.86 4.95 2.77 7.10 5.38 2.77 7.57 5.40 2.77 7.80 5.83 2.77 8.27 5.81 2.77 8.50 5.80 2.77 8.74 6.19 2.77
40 5.55 4.66 2.67 6.18 4.69 2.77 6.39 5.10 2.77 6.81 5.12 2.77 7.02 5.52 2.77 7.44 5.50 2.77 7.65 5.49 2.77 7.86 5.86 2.77
43 4.62 4.25 2.27 5.15 4.27 2.35 5.32 4.65 2.35 5.67 4.66 2.35 5.85 5.03 2.35 6.20 5.02 2.35 6.38 5.01 2.35 6.55 5.34 2.35
12+18
Outdoor temperature
Indoor temperature
30°CDB
32°CDB
18°CDB
21°CDB
23°CDB
25°CDB
16°CWB
18°CWB
27°CDB
29°CDB
19°CWB
21°CWB
22°CWB
23°CWB
12°CWB
15°CWB
°CDB
°CWB
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 5.68 4.69 0.75 6.32 4.72 0.76 6.54 5.13 0.76 6.97 5.15 0.77 7.19 5.56 0.78 7.62 5.54 0.78 7.83 5.53 0.79 8.05 5.90 0.79
5 5.68 4.69 0.89 6.32 4.72 0.90 6.54 5.13 0.91 6.97 5.15 0.92 7.19 5.56 0.92 7.62 5.54 0.93 7.83 5.53 0.94 8.05 5.90 0.94
10 5.43 4.59 1.02 6.05 4.61 1.03 6.26 5.01 1.04 6.67 5.03 1.05 6.88 5.43 1.05 7.29 5.41 1.06 7.50 5.40 1.07 7.70 5.77 1.07
15 5.31 4.53 1.30 5.91 4.56 1.32 6.12 4.96 1.33 6.52 4.98 1.34 6.72 5.37 1.35 7.12 5.35 1.36 7.32 5.34 1.37 7.53 5.70 1.38
20 5.75 4.72 2.35 6.40 4.75 2.38 6.62 5.16 2.40 7.06 5.18 2.42 7.28 5.59 2.43 7.71 5.57 2.46 7.93 5.56 2.47 8.15 5.93 2.48
25 5.86 4.77 2.17 6.53 4.80 2.20 6.76 5.21 2.21 7.20 5.23 2.24 7.42 5.65 2.25 7.87 5.63 2.27 8.09 5.62 2.28 8.31 6.00 2.29
30 5.98 4.82 2.30 6.66 4.85 2.33 6.89 5.27 2.34 7.34 5.29 2.37 7.57 5.71 2.38 8.02 5.69 2.40 8.25 5.68 2.42 8.48 6.06 2.43
35 6.08 4.86 2.67 6.78 4.89 2.77 7.01 5.31 2.77 7.47 5.34 2.77 7.70 5.76 2.77 8.16 5.74 2.77 8.39 5.73 2.77 8.62 6.11 2.77
40 5.47 4.60 2.67 6.10 4.63 2.77 6.31 5.03 2.77 6.72 5.05 2.77 6.93 5.45 2.77 7.35 5.44 2.77 7.55 5.43 2.77 7.76 5.79 2.77
43 4.56 4.20 2.27 5.08 4.22 2.35 5.26 4.59 2.35 5.60 4.61 2.35 5.78 4.97 2.35 6.12 4.95 2.35 6.29 4.95 2.35 6.47 5.28 2.35
14+14
Outdoor temperature
Indoor temperature
18°CDB
21°CDB
23°CDB
25°CDB
27°CDB
29°CDB
30°CDB
32°CDB
12°CWB
15°CWB
16°CWB
18°CWB
19°CWB
21°CWB
22°CWB
23°CWB
