- (01 - 07) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
Display panel
Display
64
1
8
7
9
3
2
5
12
13
10
14
15
16
17
20
19
18
21
1
START/STOP button
Pressed to start and stop operation
Time adjust button
Sets the current time.
2
3
4
Sleep timer button
Pressed to select sleep timer.
5
Signal transmitter
6
Timer button
Pressed to select the timer mode. (OFF TIMER, ON TIMER,
PROGRAM TIMER, TIMER RESET)
7
Fan control button
8
Battery compartment lid
9
Air flow direction set button
17
18
Clock display
21
Master control display
20
Set temperature display
Fan speed display
12
Timer set indicator
Temperature set indicator
19
Timer mode display
Set temp./Set time/
Set remote controller custom code buttons
Sets the indoor temp./ Sets the current time and on-off time.
/Sets R.C. custom code.
Master control / Code change buttons
Selects the operating mode (AUTO, HEAT, FAN, COOL, DRY).
/Start / end R.C. custom code change. (Max 4 types)
Selects the fan speed (AUTO, LOW, MED, HIGH).
10
11
14
ACL button
Air flow direction swing button
Used when replacing batteries or change the code.
15
16
Transmit indicator
TEST
RUN
11
13
Test run button
Used when testing the air conditioner after installation.
FUNCTIONS (For AU 12L, AU 14L, AU 18L)
SPECIFICATION
SIZE (H x W x D mm) 158 x 56 x 20
WEIGHT ( g ) 70
ACCESSORY Holder

Fujitsu AS*12LMACW Specifications
