– 52 –
4.4 AIR VELOCITY DISTRIBUTION
4.4.1 AIR DISCHARGE ANGLE
Horizontal
Center
Center
Center
Upward
Upward
Downward
Forward
Vertical
● AS : WALL MOUNTED
● AB : UNDER CEILING
● AB : FLOOR CONSOLE
