Fujitsu AS* G09LECB User Manual

 Indoor units: 12,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 17.49 2.46 16.94 2.53 16.37 2.60 15.79 2.68 15.44 2.72
14 12 20.57 2.57 19.92 2.64 19.25 2.72 18.57 2.79 18.17 2.84
23 19 23.32 2.63 22.58 2.70 21.82 2.78 21.05 2.86 20.59 2.91
32 28 26.45 2.63 25.61 2.71 24.74 2.79 23.88 2.87 23.35 2.91
41 37 29.51 2.64 28.58 2.71 27.61 2.79 26.65 2.87 26.06 2.92
47 43 31.47 2.77 30.48 2.85 29.45 2.93 28.42 3.00 27.79 3.00
50 47 32.56 2.30 31.53 2.37 30.47 2.44 29.40 2.51 28.75 2.55
59 50 32.47 2.19 31.44 2.26 30.38 2.32 29.32 2.39 28.67 2.43
68 59 31.43 1.84 30.44 1.90 29.41 1.95 28.38 2.01 27.76 2.04
75 65 30.88 1.90 29.91 1.95 28.90 2.01 27.88 2.06 27.27 2.10
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.13 2.46 4.96 2.53 4.80 2.60 4.63 2.68 4.53 2.72
-10.0 -11.1 6.03 2.57 5.84 2.64 5.64 2.72 5.44 2.79 5.32 2.84
-5.0 -7.2 6.83 2.63 6.62 2.70 6.39 2.78 6.17 2.86 6.03 2.91
0.0 -2.2 7.75 2.63 7.51 2.71 7.25 2.79 7.00 2.87 6.84 2.91
5.0 2.8 8.65 2.64 8.38 2.71 8.09 2.79 7.81 2.87 7.64 2.92
8.3 6.1 9.22 2.77 8.93 2.85 8.63 2.93 8.33 3.00 8.15 3.00
10.0 8.3 9.54 2.30 9.24 2.37 8.93 2.44 8.62 2.51 8.43 2.55
15.0 10.0 9.52 2.19 9.22 2.26 8.90 2.32 8.59 2.39 8.40 2.43
20.0 15.0 9.21 1.84 8.92 1.90 8.62 1.95 8.32 2.01 8.14 2.04
23.9 18.3 9.05 1.90 8.77 1.95 8.47 2.01 8.17 2.06 7.99 2.10
 Indoor units: 7,000 Btu + 7,000 Btu + 7,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.48 2.40 15.96 2.46 15.42 2.54 14.88 2.61 14.55 2.65
14 12 19.17 2.50 18.57 2.57 17.94 2.65 17.31 2.72 16.93 2.77
23 19 21.72 2.61 21.03 2.68 20.32 2.76 19.61 2.84 19.18 2.88
32 28 24.86 2.78 24.08 2.86 23.26 2.94 22.45 3.00 21.96 3.00
41 37 28.16 2.66 27.27 2.73 26.35 2.81 25.43 2.89 24.87 2.94
47 43 30.03 2.68 29.08 2.76 28.10 2.84 27.12 2.92 26.52 2.97
50 47 31.15 2.71 30.17 2.79 29.15 2.87 28.13 2.95 27.51 3.00
59 50 32.65 2.71 31.62 2.79 30.55 2.87 29.48 2.95 28.83 3.00
68 59 29.96 2.10 29.01 2.16 28.03 2.22 27.05 2.28 26.45 2.32
75 65 27.94 1.64 27.05 1.69 26.14 1.74 25.22 1.78 24.67 1.81
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.83 2.40 4.68 2.46 4.52 2.54 4.36 2.61 4.26 2.65
-10.0 -11.1 5.62 2.50 5.44 2.57 5.26 2.65 5.07 2.72 4.96 2.77
-5.0 -7.2 6.37 2.61 6.16 2.68 5.96 2.76 5.75 2.84 5.62 2.88
0.0 -2.2 7.29 2.78 7.06 2.86 6.82 2.94 6.58 3.00 6.43 3.00
5.0 2.8 8.25 2.66 7.99 2.73 7.72 2.81 7.45 2.89 7.29 2.94
8.3 6.1 8.80 2.68 8.52 2.76 8.24 2.84 7.95 2.92 7.77 2.97
10.0 8.3 9.13 2.71 8.84 2.79 8.54 2.87 8.24 2.95 8.06 3.00
15.0 10.0 9.57 2.71 9.27 2.79 8.95 2.87 8.64 2.95 8.45 3.00
20.0 15.0 8.78 2.10 8.50 2.16 8.21 2.22 7.93 2.28 7.75 2.32
23.9 18.3 8.19 1.64 7.93 1.69 7.66 1.74 7.39 1.78 7.23 1.81
- 234 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu AS* G09LECB Specifications

General

Brand	Fujitsu
Model	AS* G09LECB
Category	Air Conditioner
Language	English
