2) Ducted
Combination of indoor unit
Rated capacity for each indoor unit
(kBtu/h)
Maximum capacity for each indoor
unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
Room 1 Room 2 Room 3 Room 4 Total Room 1 Room 2 Room 3 Room 4 Room 1 Room 2 Room 3 Room 4 Min. Rated Max. Min. Rated Max.
18 18 - -
36*
1
17.30 17.30 - - 20.00 20.00 - - 11.00 34.60 40.00 1.02 3.21 3.85
7 7 18 - 32 7.20 7.20 18.60 - 8.70 8.70 21.70 - 11.00 33.00 39.10 0.87 3.07 3.76
7 7 24 - 38 6.70 6.70 23.00 - 7.50 7.50 26.00 - 11.00 36.40 41.00 0.87 3.38 3.95
7 9 12 - 28 7.20 9.30 12.40 - 8.80 11.30 14.90 - 11.00 28.90 35.00 0.87 2.68 3.37
7 9 18 - 34 7.10 9.10 18.40 - 8.30 10.80 21.10 - 11.00 34.60 40.20 0.87 3.21 3.87
7 12 12 - 31 7.20 12.40 12.40 - 8.80 14.90 14.90 - 11.00 32.00 38.60 0.87 2.97 3.72
7 12 18 - 37 6.90 11.80 17.70 - 7.70 13.30 20.00 - 11.00 36.40 41.00 0.87 3.38 3.95
9 9 9 - 27 9.30 9.30 9.30 - 11.30 11.30 11.30 - 11.00 27.90 33.90 0.87 2.59 3.26
9 9 12 - 30 9.30 9.30 12.40 - 11.30 11.30 14.90 - 11.00 31.00 37.50 0.87 2.88 3.61
9 9 18 - 36 9.10 9.10 18.20 - 10.20 10.20 20.60 - 11.00 36.40 41.00 0.87 3.38 3.95
9 12 12 - 33 9.10 12.20 12.20 - 10.90 14.50 14.50 - 11.00 33.50 39.90 0.87 3.11 3.84
9 12 18 - 39 8.50 11.20 16.70 - 9.40 12.60 19.00 - 11.00 36.40 41.00 0.97 3.38 3.95
12 12 12 - 36 12.10 12.10 12.20 - 13.60 13.60 13.60 - 11.00 36.40 40.80 0.87 3.38 3.93
7 7 7 7 28 7.20 7.20 7.20 7.20 8.80 8.80 8.80 8.80 11.00 28.80 35.20 0.87 2.55 3.19
7 7 7 9 30 7.20 7.20 7.20 9.30 8.80 8.80 8.80 11.30 11.00 30.90 37.70 0.87 2.73 3.42
7 7 7 12 33 7.10 7.10 7.10 12.20 8.50 8.50 8.50 14.40 11.00 33.50 39.90 0.87 2.96 3.66
7 7 7 18 39 6.50 6.50 6.50 16.90 7.50 7.50 7.50 19.50 11.00 36.40 42.00 0.87 3.22 3.85
7 7 9 9 32 7.20 7.20 9.30 9.30 8.60 8.60 11.10 11.10 11.00 33.00 39.40 0.87 2.92 3.58
7 7 9 12 35 7.10 7.10 9.20 12.20 8.30 8.30 10.70 14.30 11.00 35.60 41.60 0.87 3.15 3.81
7 7 12 12 38 6.70 6.70 11.50 11.50 7.70 7.70 13.30 13.30 11.00 36.40 42.00 0.87 3.22 3.85
7 9 9 9 34 7.10 9.20 9.20 9.20 8.50 10.90 10.90 10.90 11.00 34.70 41.20 0.87 3.07 3.78
7 9 9 12 37 6.90 8.90 8.90 11.70 8.00 10.20 10.20 13.60 11.00 36.40 42.00 0.87 3.22 3.85
9 9 9 9 36 9.10 9.10 9.10 9.10 10.50 10.50 10.50 10.50 11.00 36.40 42.00 0.87 3.22 3.85
9 9 9 12 39 8.40 8.40 8.40 11.20 9.69 9.69 9.69 12.93 11.00 36.40 42.00 0.87 3.22 3.85
NOTES:
•
*
1
: Optional kit K9FZ1818 (UTP-MU36A2) shall be necessary for the dual zone system “18
+ 18”.
•
*
2
: Wall mounted 18 type cannot be connected in this combination.
• Specifications are based on the following conditions.
– Power source of specifications: 230 V
– 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 15: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
– 3 or more indoor units should be connected. (Only the combinations of the “18 + 18” can be
connected by using the optional kit K9FZ1818 (UTP-MU36A2).)
– Heating: Indoor temperature of 70 °FDB (21.1 °CDB)/ 60 °FWB (15.6 °CWB), and outdoor
temperature of 47 °FDB (8.3 °CDB) / 43 °FWB (6.1 °CWB).
– Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit—Indoor unit]
– The total ability of connected indoor units is from 27,000 Btu up to 39,000 Btu.
– Non-Ducted system combinations input are based on wall mount models. The input of combi-
nations including cassette models may be a little higher.
– Ducted system combinations capacities are based on slim duct units excepting 7,000-Btu
models. 7,000 Btu models are based on wall mount models.
- 258 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1
