Fujitsu AS* G09LECB User Manual

 Indoor units: 9,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 8.79 6.85 0.35 9.94 6.91 0.36 10.47 7.55 0.36 11.21 7.92 0.37 11.99 8.10 0.37 12.36 9.00 0.37
23 8.56 6.77 0.41 9.67 6.83 0.42 10.19 7.46 0.42 10.91 7.83 0.43 11.67 8.01 0.43 12.03 8.90 0.43
32 8.54 6.69 0.47 9.65 6.75 0.48 10.17 7.37 0.48 10.89 7.73 0.49 11.64 7.91 0.49 12.00 8.79 0.49
41 8.35 6.64 0.58 9.44 6.70 0.59 9.95 7.31 0.59 10.66 7.67 0.60 11.39 7.85 0.61 11.74 8.73 0.61
50 8.34 6.63 0.58 9.43 6.69 0.59 9.94 7.30 0.59 10.64 7.66 0.60 11.38 7.84 0.60 11.73 8.71 0.61
59 8.26 6.61 0.57 9.34 6.67 0.58 9.85 7.29 0.59 10.54 7.65 0.59 11.27 7.82 0.60 11.62 8.70 0.60
67 8.86 6.77 0.69 10.01 6.83 0.71 10.56 7.46 0.71 11.30 7.83 0.72 12.08 8.01 0.73 12.46 8.90 0.73
77 9.46 6.93 0.87 10.69 6.99 0.89 11.27 7.63 0.90 12.06 8.01 0.91 12.90 8.19 0.92 13.30 9.10 0.92
87 9.35 6.92 1.05 10.57 6.98 1.07 11.14 7.62 1.08 11.93 8.00 1.09 12.75 8.19 1.11 13.14 9.10 1.11
95 9.24 6.92 1.24 10.45 6.98 1.26 11.01 7.62 1.27 11.79 8.00 1.28 12.60 8.18 1.30 12.99 9.09 1.30
104 7.32 6.10 0.96 8.27 6.15 0.98 8.72 6.72 0.99 9.34 7.05 1.00 9.98 7.22 1.01 10.29 8.02 1.02
115 5.40 4.79 0.69 6.10 5.12 0.71 6.43 5.59 0.71 6.89 5.87 0.72 7.36 6.00 0.73 7.59 6.67 0.73
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 2.58 2.01 0.35 2.91 2.02 0.36 3.07 2.21 0.36 3.29 2.32 0.37 3.51 2.37 0.37 3.62 2.64 0.37
-5.0 2.51 1.98 0.41 2.83 2.00 0.42 2.99 2.19 0.42 3.20 2.29 0.43 3.42 2.35 0.43 3.52 2.61 0.43
0.0 2.50 1.96 0.47 2.83 1.98 0.48 2.98 2.16 0.48 3.19 2.27 0.49 3.41 2.32 0.49 3.52 2.58 0.49
5.0 2.45 1.95 0.58 2.77 1.96 0.59 2.92 2.14 0.59 3.12 2.25 0.60 3.34 2.30 0.61 3.44 2.56 0.61
10.0 2.45 1.94 0.58 2.76 1.96 0.59 2.91 2.14 0.59 3.12 2.25 0.60 3.33 2.30 0.60 3.44 2.55 0.61
15.0 2.42 1.94 0.57 2.74 1.96 0.58 2.89 2.14 0.59 3.09 2.24 0.59 3.30 2.29 0.60 3.40 2.55 0.60
19.4 2.60 1.98 0.69 2.94 2.00 0.71 3.09 2.19 0.71 3.31 2.29 0.72 3.54 2.35 0.73 3.65 2.61 0.73
25.0 2.77 2.03 0.87 3.13 2.05 0.89 3.30 2.24 0.90 3.54 2.35 0.91 3.78 2.40 0.92 3.90 2.67 0.92
30.6 2.74 2.03 1.05 3.10 2.05 1.07 3.27 2.23 1.08 3.50 2.34 1.09 3.74 2.40 1.11 3.85 2.67 1.11
35.0 2.71 2.03 1.24 3.06 2.04 1.26 3.23 2.23 1.27 3.46 2.34 1.28 3.69 2.40 1.30 3.81 2.66 1.30
40.0 2.15 1.79 0.96 2.42 1.80 0.98 2.56 1.97 0.99 2.74 2.07 1.00 2.93 2.11 1.01 3.02 2.35 1.02
46.1 1.58 1.40 0.69 1.79 1.50 0.71 1.88 1.64 0.71 2.02 1.72 0.72 2.16 1.76 0.73 2.22 1.95 0.73
 Indoor units: 12,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 10.08 7.87 0.39 11.39 7.94 0.40 12.01 8.68 0.40 12.86 9.10 0.41 13.75 9.31 0.41 14.17 10.35 0.42
23 9.81 7.78 0.46 11.09 7.85 0.47 11.69 8.57 0.47 12.51 9.00 0.48 13.38 9.21 0.48 13.79 10.23 0.48
32 9.79 7.69 0.52 11.06 7.76 0.53 11.66 8.47 0.54 12.48 8.89 0.54 13.34 9.10 0.55 13.76 10.11 0.55
41 9.58 7.63 0.65 10.82 7.70 0.66 11.41 8.41 0.67 12.22 8.82 0.67 13.06 9.03 0.68 13.46 10.03 0.68
50 9.57 7.62 0.65 10.81 7.69 0.66 11.40 8.39 0.66 12.20 8.81 0.67 13.04 9.01 0.68 13.45 10.02 0.68
59 9.48 7.61 0.64 10.71 7.67 0.65 11.29 8.38 0.66 12.09 8.79 0.67 12.92 9.00 0.67 13.32 10.00 0.68
67 10.16 7.78 0.78 11.48 7.85 0.79 12.10 8.58 0.80 12.96 9.00 0.81 13.85 9.21 0.81 14.28 10.23 0.82
77 10.84 7.96 0.98 12.26 8.03 0.99 12.92 8.77 1.00 13.83 9.20 1.01 14.79 9.42 1.03 15.24 10.47 1.03
87 10.72 7.96 1.18 12.12 8.03 1.20 12.77 8.77 1.21 13.68 9.20 1.22 14.62 9.41 1.24 15.07 10.46 1.25
95 10.60 7.95 1.38 11.98 8.02 1.41 12.63 8.76 1.42 13.52 9.19 1.44 14.45 9.41 1.45 14.90 10.45 1.46
104 8.39 7.01 1.08 9.49 7.07 1.10 10.00 7.73 1.11 10.71 8.11 1.12 11.44 8.30 1.13 11.80 9.22 1.14
115 6.19 5.50 0.78 6.99 5.88 0.79 7.37 6.43 0.80 7.89 6.74 0.81 8.44 6.90 0.82 8.70 7.67 0.82
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 2.95 2.31 0.39 3.34 2.33 0.40 3.52 2.54 0.40 3.77 2.67 0.41 4.03 2.73 0.41 4.15 3.03 0.42
-5.0 2.87 2.28 0.46 3.25 2.30 0.47 3.43 2.51 0.47 3.67 2.64 0.48 3.92 2.70 0.48 4.04 3.00 0.48
0.0 2.87 2.25 0.52 3.24 2.27 0.53 3.42 2.48 0.54 3.66 2.61 0.54 3.91 2.67 0.55 4.03 2.96 0.55
5.0 2.81 2.24 0.65 3.17 2.26 0.66 3.34 2.46 0.67 3.58 2.59 0.67 3.83 2.65 0.68 3.95 2.94 0.68
10.0 2.80 2.23 0.65 3.17 2.25 0.66 3.34 2.46 0.66 3.58 2.58 0.67 3.82 2.64 0.68 3.94 2.94 0.68
15.0 2.78 2.23 0.64 3.14 2.25 0.65 3.31 2.46 0.66 3.54 2.58 0.67 3.79 2.64 0.67 3.90 2.93 0.68
19.4 2.98 2.28 0.78 3.37 2.30 0.79 3.55 2.51 0.80 3.80 2.64 0.81 4.06 2.70 0.81 4.19 3.00 0.82
25.0 3.18 2.33 0.98 3.59 2.35 0.99 3.79 2.57 1.00 4.05 2.70 1.01 4.33 2.76 1.03 4.47 3.07 1.03
30.6 3.14 2.33 1.18 3.55 2.35 1.20 3.74 2.57 1.21 4.01 2.70 1.22 4.28 2.76 1.24 4.42 3.07 1.25
35.0 3.11 2.33 1.38 3.51 2.35 1.41 3.70 2.57 1.42 3.96 2.69 1.44 4.24 2.76 1.45 4.37 3.06 1.46
40.0 2.46 2.06 1.08 2.78 2.07 1.10 2.93 2.26 1.11 3.14 2.38 1.12 3.35 2.43 1.13 3.46 2.70 1.14
46.1 1.81 1.61 0.78 2.05 1.72 0.79 2.16 1.88 0.80 2.31 1.98 0.81 2.47 2.02 0.82 2.55 2.25 0.82
- 260 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu AS* G09LECB Specifications
