2. MODEL SELECTION
HEATING CAPACITY
HEATING CAPACITY4-2.
MODEL : AO


G45LBT8
Capacity in kW

Indoor unit
connecting
capacity (%)
Outdoor
temperature
Indoor temperature
DB WB
16.0°C DB 18.0°C DB 20.0°C DB 24.0°C DB
°C °C
TC IP TC IP TC IP TC IP
130
-15.0 -16.0 12.0 5.59 11.5 5.61 11.2 5.64 10.6 5.69
-10.0 -11.0 15.0 5.66 14.7 5.67 14.5 5.69 14.1 5.71
-5.0 -7.0 15.8 5.76 15.6 5.77 15.4 5.79 15.2 5.81
0.0 -2.0 17.0 5.86 16.7 5.88 16.5 5.90 16.3 5.91
5.0 3.0 18.0 5.93 17.8 5.95 17.6 5.97 17.4 5.98
7.0 6.0 19.0 5.98 18.7 5.98 18.4 5.98 18.2 5.98
10.0 8.0 19.7 5.98 19.5 5.98 19.3 5.98 19.1 5.98
15.0 10.0 20.4 5.98 20.2 5.98 20.0 5.98 19.8 5.98
20.0 15.0 20.7 5.98 20.5 5.98 20.4 5.98 20.1 5.98
120
-15.0 -16.0 11.4 5.57 11.0 5.58 10.6 5.60 10.2 5.62
-10.0 -11.0 14.5 5.62 14.3 5.64 14.0 5.66 13.7 5.68
-5.0 -7.0 15.6 5.71 15.4 5.74 15 .1 5.77 14.9 5.79
0.0 -2.0 16.8 5.80 16.5 5.82 16.3 5.86 16.1 5.88
5.0 3.0 17.8 5.92 17.6 5.93 17.4 5.95 17.2 5.96
7.0 6.0 18.7 5.98 18.5 5.98 18.2 5.98 18.0 5.98
10.0 8.0 19.4 5.98 19.1 5.98 18.9 5.98 18.7 5.98
15.0 10.0 20.1 5.10 19.9 5.22 19.6 5.45 19.4 5.84
20.0 15.0 20.4 4.37 20.2 4.44 20.1 4.73 19.9 5.05
110
-15.0 -16.0 11.0 5.55 10.5 5.57 10.0 5.59 9.7 5.60
-10.0 -11.0 13.7 5.59 13.5 5.61 13.3 5.63 13.1 5.65
-5.0 -7.0 14.8 5.56 14.6 5.71 14.4 5.74 14.2 5.73
0.0 -2.0 15.9 5.52 15.7 5.79 15.5 5.84 15.3 5.85
5.0 3.0 16.9 5.04 16.7 5.22 16.4 5.36 16.2 5.55
7.0 6.0 17.8 4.75 17.6 5.00 17.4 5.30 17.2 5.37
10.0 8.0 18.5 4.63 18.2 4.89 18.0 5.18 17.8 5.27
15.0 10.0 19.4 4.40 19.1 4.66 18.8 4.88 18.5 5.03
20.0 15.0 19.9 4.23 19.6 4.43 19.4 4.61 19.2 4.72
100
-15.0 -16.0 10.5 5.55 10.0 5.52 9.6 5.50 9.2 5.48
-10.0 -11.0 12.8 5.60 12.2 5.61 11.8 5.62 11.3 5.64
-5.0 -7.0 14.4 5.70 13.8 5.78 13.3 5.75 12.9 5.72
0.0 -2.0 15.7 5.76 15.1 5.78 14.5 5.74 13.8 5.68
5.0 3.0 17.0 5.76 16.2 5.61 15.0 5.23 14.0 4.92
7.0 6.0 18.5 5.70 17.4 5.35 16.0 5.07 14.5 4.55
10.0 8.0 18.6 5.56 17. 5 5.25 16.2 4.80 14.7 4.53
15.0 10.0 18.8 5.19 17.6 4.80 16.4 4.61 15.0 4.33
20.0 15.0 19.0 4.63 17.8 4.45 16.7 4.36 15.4 4.08
90
-15.0 -16.0 10.2 5.45 9.7 5.41 9.4 5.38 9.1 5.32
-10.0 -11.0 12.1 5.53 11.7 5.36 11.4 5.20 11.1 5.17
-5.0 -7.0 13.0 5.55 12.2 5.29 12.0 5.15 11.7 5.08
0.0 -2.0 14.1 5.30 13.0 4.96 12.6 4.84 12.4 4.77
5.0 3.0 15.2 5.17 14.1 4.71 13.7 4.55 12.9 4.46
7.0 6.0 16.4 5.02 15.1 4.65 14.2 4.36 13.3 4.16
10.0 8.0 16.6 4.86 15.2 4.54 14.9 4.14 13.7 3.95
15.0 10.0 17.1 4.47 16.0 4.11 15.5 3.92 14.0 3.77
20.0 15.0 17. 5 4.14 16.6 3.83 16.2 3.73 14.4 3.53
80
-15.0 -16.0 9.3 5.22 9.2 5.15 9.1 5.12 9.0 5.08
-10.0 -11.0 10.7 5.01 10.3 4.98 9.9 4.95 9.7 4.92
-5.0 -7.0 11.3 4.86 10.9 4.81 10.6 4.71 10.3 4.66
0.0 -2.0 12.4 4.48 11.9 4.40 11.3 4.32 10.9 4.26
5.0 3.0 13.4 4.17 12.7 4.10 12.0 4.06 11.4 3.81
7.0 6.0 14.5 3.99 13.7 3.91 12.7 3.85 12.0 3.54
10.0 8.0 14.8 3.95 13.9 3.84 13.1 3.82 12.3 3.50
15.0 10.0 15.3 3.86 14.5 3.74 13.9 3.70 12.7 3.45
20.0 15.0 15.7 3.65 15.1 3.56 14.6 3.55 13.4 3.22
TC : Total Capacity kW.
IP : Input Power kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 14) -
