6. SYSTEM DESIGN
DUCT STATIC PRESSURE SETTING5-10.
MODELS : AR
G07LLTA, AR
G09LLTA, AR
G12LLTA,
AR
G14LLTA, AR
G18LLTA,
AR
G12LLTB, AR
G14LLTB, AR
G18LLTB
he airow setting other than the deaut aue o Pa a be changed to the reuired
external static pressure.
etting o the airow can be changed with the wireess reote controer wired reote
controller and simple remote controller.
ow to set airow eterna static pressure
W ireless remote controller
irow is set b unction nuber static pressure.
Refer to "BUTTON NANE AND FUNCTION", "FUNCTION SETTING" and "FUNCTION
DETAILS" in 5-3 INDOOR UNIT (setting by wireless remote controller).
Wired remote controller
irow is set b unction nuber static pressure.
Refer to "BUTTON NANE AND FUNCTION", "FUNCTION SETTING" and "FUNCTION
DETAILS" in 5-4. INDOOR UNIT (setting by wired remote controller).
Simple remote controller
irow is set b unction nuber static pressure.
Refer to "BUTTON NANE AND FUNCTION", "FUNCTION SETTING" and "FUNCTION
DETAILS" in 5-5 INDOOR UNIT (setting by simple remote controller).
FAN PERFORMANCE CURVE
Refer to Chapter 4. INDOOR UNITS
Caution
If airflow setting is inadequate, it may cause a decrease in airflow or water leakage due to
wrong operation.
