12
SWING OPERATION
To select SWING Operation
Press the SWING LOUVER button (Fig. 5 O).
The SWING indicator lamp (orange) (Fig. 3 7) will light.
In this mode, the Air Flow Direction Louvers will swing automatically to direct the
air flow both up and down.
To Stop SWING Operation
Press the SWING LOUVER button (Fig. 5 O) once again.
The SWING indicator lamp (orange) (Fig. 3 7) will go out.
Airflow direction will return to the setting before swing was begun.
About Swing Operation
● The range of swing is relative to the currently set airflow
direction.
● During Cooling/Dry modes, if SWING Operation in con-
tinued at the lowest (downward) range for more than 30
minutes, the unit will automatically switch the swing range
to the horizontal flow range, to prevent the condensation
of moisture on the outlet.
MANUAL AUTO OPERATION
Use the MANUAL AUTO operation in the event the Remote Control Unit is lost or otherwise unavailable.
How To Use the Main Unit Controls
Press the MANUAL AUTO button (Fig. 2 2) on the main unit
control panel.
To stop operation, press the MANUAL AUTO button once again.
(Controls are located inside the Intake Grille)
● When the air conditioner is operated
with the controls on the Main Unit, it
will operate under the same mode as
the AUTO mode selected on the Re-
mote Control Unit (see page 7-8).
● The fan speed selected will be “AUTO”
and the thermostat setting will be
standard.
● The SWING operation may stop temporarily when the
air conditioner’s fan is not operating, or when operating
at very low speeds.
Begin air conditioner operation before performing this procedure.
